Take your productivity to the next level with the UltrArmor UA7 endpoint device, powered by AMD Ryzen™ Embedded R2514 processor, maximizing Graphics Performance. The UA7 has up to 4 UHD/4K displays to maximize the efficiency across your business.
- Features
- Specification
- Downloads
Next-Gen Productivity
Built for the industrial-strength environment, the UA7 equipped with AMD Ryzen™ Embedded R2514 processor effectively improves performance. Driving exponential productivity with the trustworthy thin client device
Support Up to 9 USB Ports With USB-C
High competitive thin client device built with 8 USB ports and 1 USB-C support, enhancing capacity in the Hybrid cloud workforce
Enhance Security and Reliability
UA7 supports robust protection with Hardware Validated Boot (HVB), an AMD-specific form of secure boot, providing the foundation trust of hardware products. The higher the security, the fewer problems you'll have
Design for Users Requiring 4 Multi-Display
Experience high-definition visual environments with native support for up to 4 UHD/4K displays. UA7 is the top choice for users requiring high multimedia performance
|
Performance |
|
|
CPU |
AMD Ryzen™ Embedded R2514 processor 2.1GHz base clock up to 3.7GHz boost frequency, Quad Core eight threads |
|
Memory |
8GB DDR4-2667MHz dual channel (up to 32GB optional) |
|
Multiple Display |
4 DP 1.4 and 1 USB-C DP Alt Mode (DP 4 alternative) |
|
Display Resolution |
4K 60Hz (Max) |
|
Graphic & Design |
• AMD Radeon™ Graphics with up to 8 compute units, 1.2GHz Max • HEVC, VP9, and AVC decode support • Support AVX2 instruction sets |
|
Expandability |
|
|
WiFi (Optional) |
• M.2 for WiFi module (E Key) • 2 external antenna holes reserved |
|
Storage |
• On board 8GB eMMC as default (up to 64GB optional) • M.2 for SSD installation (M key, 2242/2280, SATA/PCIe x4) |
|
LAN |
RJ-45 10/100/1000Mbps |
|
USB |
6 USB 2.0-A, 2 USB-A 3.2 Gen2, 1 USB-C 3.2 Gen2 with DP Alt Mode |
|
Audio |
Combo audio jack for headset & internal speaker |
|
Smart Card Reader |
Build in Omnikey smart card reader (Optional) |
|
Power |
DC 12V/ 5A 60W power adapter |
|
Manageability / Security |
|
|
Processor Security |
• AMD Memory Guard • AMD Secure Processor |
|
Security Lock |
Kensington lock slot |
|
WoL |
RJ45 LAN with standby power design supports Magic Packet wake-up event |
|
TPM |
Infineon TPM 2.0 |
|
Environment |
|
|
Cooling |
Passive cooling |
|
Operating Temperature |
0 °C to 35 °C, 32 °F to 95 °F in vertical position |
|
Operating Humidity |
20% - 80% non-condensing |
|
ECO design |
30% Post-consumer recycled plastic (PCR) for plastic housing |
-
UltrArmor UA7_Datasheet
